Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days

Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days
Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days

Large Image :  Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days

Product Details:
Place of Origin: Guangdong, China
Brand Name: HEYA
Certification: ISO9001
Model Number: HY-404
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Coated with anticorrosive oil , packed in carton box
Delivery Time: 15-20 work days
Payment Terms: T/T,D/A,D/P,Western Union
Supply Ability: 50 pcs/week
Contact Now Chat Now

Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days

Description
Product Name: Auto Lamp Mould Highlight: High-Precision Uniform Textures
Tolerance: +/-0.001mm Hardness: 43-47 HRC
Feature: Durable Processing Method: Electroforming Processing
Material: Stainless Steel, Brass, Aluminum, Tin, And Other Metal Alloys Application: Biomedical Industry
Material: Nickel Heat Resistance: High
Corrosion Resistance: Excellent Mold Life: Long
Conductivity: High Shape: Customized
Application: Electroforming Process Durability: High
Surface Finish: Polished Thickness: Depends On Design
Highlight:

Customizable auto lamp mould

,

ProE designed car light mould

,

Fast delivery auto lamp mould

Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days
Product Specifications
Attribute Value
Product Name Auto Lamp Mould
Highlight High-Precision Uniform Textures
Tolerance +/-0.001mm
Hardness 43-47 HRC
Feature Durable
Processing Method Electroforming Processing
Material Stainless steel, brass, aluminum, tin, and other metal alloys
Application Biomedical Industry
Customizable ProE Designed Auto Lamp Mould | Fast Delivery in 15-20 Days
Engineered for speed and precision, our customizable auto lamp moulds leverage ProE (Creo) design software to deliver tailored solutions for automotive lighting components--with fast delivery timelines of 30-60 days. Specializing in headlights, taillights, fog lights, and signal lamps, we combine advanced 3D design capabilities with streamlined manufacturing to meet tight project deadlines without compromising on optical accuracy or automotive-grade durability.
Attribute Value
Product Name Customizable Auto Lamp Mould
Design Software ProE (Creo) Mold Design Module (parametric 3D modeling)
Customization Scope Headlights (LED, matrix, adaptive), taillights, fog lights, signal lamps
Delivery Time 30-60 days (prototype to production mould)
Precision Dimensional tolerance: ±0.01mm; Surface roughness: Ra ≤0.01μm
Materials S136 (corrosion-resistant), H13 (heat-resistant), NAK80 (pre-hardened)
Certification IATF 16949, ISO 9001, ECE R112 (automotive lighting standards)
Core Advantages: Speed, Precision & Customization
1. ProE (Creo) Design: Engineering Excellence for Auto Lamp Precision
ProE's parametric 3D modeling drives accuracy and efficiency in mould design:
  • Optical Feature Replication: ProE's advanced tools simulate light flow and mold filling, ensuring precise replication of critical optical features--such as lens curvatures, reflector facets, and light guides--with 99.8% fidelity. This eliminates light distortion, a must for compliance with ECE R112 and SAE J578 standards.
  • DFM Integration: Built-in Design for Manufacturability (DFM) analysis in ProE identifies potential issues (e.g., undercuts, uneven wall thickness) early, reducing design revisions by 40% and accelerating the development cycle.
  • Data Compatibility: Seamless integration with CAM systems streamlines CNC machining, translating ProE designs directly into micron-level precision on physical moulds--critical for tight-tolerance auto lamp components.
2. Full Customization for Diverse Auto Lamp Types
We tailor moulds to your specific auto lamp design, supporting:
  • Headlights: Moulds for LED, matrix, and adaptive headlights, with cavities optimized for complex lens geometries and heat sink integration (compatible with PC/PMMA resins).
  • Taillights: Custom moulds for dynamic signal lamps, featuring micro-textured surfaces for uniform light diffusion and decorative trim details.
  • Fog Lights: Heat-resistant moulds (H13 steel) to handle high-temperature resins, with precision venting to prevent defects in small, compact designs.
  • Material-Specific Tuning: Moulds optimized for PC (impact resistance), PMMA (clarity), and PC/ABS blends (durability), with cooling channels tailored to resin flow properties.
3. Fast Delivery: 30-60 Days from Design to Production
Our streamlined process ensures rapid turnaround without sacrificing quality:
  • Accelerated Design Phases: ProE's parametric modeling cuts design time by 25% vs. traditional methods, with reusable templates for common lamp features (e.g., reflector patterns) speeding iterations.
  • Rapid Prototyping: 3D-printed prototype moulds (SLA/CNC) delivered in 7-10 days for design validation, followed by fast-track production mould manufacturing.
  • Modular Tooling: Standardized components (e.g., guide pillars, ejector systems) from trusted suppliers (LKM, HASCO) reduce lead times, while custom cores/cavities are prioritized for machining.
  • Project Management: Dedicated teams oversee each stage (design, machining, testing) with real-time progress tracking, ensuring on-time delivery within the 30-60 day window.
Delivery Timeline Breakdown
Stage Timeline (Days) Key Activities
Design & DFM Approval 5-7 ProE design finalization, optical simulation, and client sign-off.
Prototype Mould 7-10 3D-printed or single-cavity trial mould for functional and optical testing.
Production Mould Machining 15-30 CNC machining of cores/cavities, heat treatment, and surface polishing.
Assembly & Testing 3-5 Mould assembly, trial runs with production resins, and final inspection.
Total 30-60 From design kickoff to delivery of production-ready mould.
Application Scenarios
Our moulds serve global automakers and Tier 1 suppliers, supporting:
  • Passenger Vehicles: Luxury and mass-market cars requiring high-precision headlights and taillights.
  • Commercial Vehicles: Heavy-duty truck fog lights and signal lamps (durability-focused designs).
  • Electric Vehicles (EVs): Custom moulds for integrated LED light bars and aerodynamic lamp housings.
Quality & Service Commitment
  • Precision Validation: Each mould undergoes CMM inspection (±0.001mm accuracy) and optical testing (light transmittance, beam pattern) to verify compliance with design specs.
  • Automotive-Grade Compliance: Certified to IATF 16949, with full traceability for materials, design files, and production records--meeting OEM audit requirements.
  • Post-Delivery Support: 30-day warranty on mould performance, with technical teams available for process optimization and troubleshooting.
Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days 0
Customizable ProE Designed Auto Lamp Mould For Fast Mould Delivery In 15-20 Days 1
For auto lamp manufacturers needing customizable, precision moulds delivered quickly, our ProE-designed solutions balance speed, accuracy, and automotive durability--turning your lighting designs into production-ready reality in 30-60 days.
