Description
Product Name: Mold Core Pin Highlight: High-Precision Uniform Textures
Tolerance: +/-0.001mm Hardness: 43-47 HRC
Feature: Durable Processing Method: Electroforming Processing
Material: Nickel Application: Biomedical Industry
Highlight:

Nickel alloy electroplated mold cavity

,

High precision core cavity mold

,

Milling drilling process mold core

High Precision Nickel Alloy Electroplated Mold Cavity And Core With Milling Drilling Process
Engineered for molds requiring ultra-precise holes/grooves with stable nickel alloy performance, our high-precision nickel alloy electroplated mold cavities and cores combine electroforming and precision milling/drilling processes to deliver ±0.001mm tolerance for critical features.
Product Specifications
Attribute Value
Product Name High Precision Nickel Alloy Electroplated Mold Cavity and Core
Highlight Milling-drilled precision holes/grooves, nickel alloy corrosion resistance, ±0.001mm hole position accuracy
Tolerance ±0.001mm (critical features); ±0.003mm (general areas)
Hardness 50-55 HRC (nickel-cobalt alloy); 45-50 HRC (high-purity nickel)
Feature Ra ≤0.008μm surface finish, hole coaxiality ≤0.0008mm, groove parallelism ≤0.001mm
Processing Method Electroplating + Precision milling + High-speed drilling
Material High-purity nickel (99.95%), nickel-cobalt alloy, nickel-copper alloy
Application Automotive ADAS sensors, medical micro-connectors, industrial automation precision gears, optical component housings
High Precision Nickel Alloy Electroplated Mold Cavity And Core With Milling Drilling Process 0
Core Advantages: Electroplating + Milling Drilling = Precision Holes & Grooves
Our hybrid manufacturing approach combines the benefits of electroforming and precision machining to overcome the limitations of each individual process.
Precision Milling Drilling: Master of Complex, Accurate Holes/Grooves
  • Complex Hole System Processing: Drills multi-row micro-holes (0.07-0.5mm diameter) with ±0.001mm hole position accuracy and ≤0.0008mm coaxiality
  • High-Precision Groove Shaping: Mills narrow grooves (0.08-2mm width) with ±0.001mm tolerance and ≤0.001mm parallelism
  • No Hard Alloy Wear: Uses carbide-tipped tools optimized for nickel alloy (50-55 HRC), ensuring consistent precision across 100+ mold units
±0.001mm High Precision: Double Guarantee from Electroplating + Machining
  • Electroplating's Stable Base: Deposits uniform nickel alloy layers (thickness tolerance ±0.0005mm)
  • Milling/Drilling's Fine Trimming: Corrects minor electroforming deviations and shapes holes/grooves to ±0.001mm
  • Dimensional Stability: Low thermal expansion (13.1*10⁻⁶/℃) preserves tolerance through 150,000+ production cycles at 200℃
Nickel Alloy Durability: Built for High-Cycle, High-Stress Use
  • Corrosion Resistance: Resists industrial coolants, medical disinfectants, and humidity
  • Wear-Proof Performance: Extends mold life to 200,000+ cycles (vs. 80,000 for standard steel molds)
  • Low Maintenance: Ra ≤0.008μm smoothness reduces material adhesion, cutting cleaning time by 40%
Application Scenarios
Our molds excel in industries where micron-level hole/groove accuracy is critical to product functionality:
  • Automotive Electronics: ADAS sensor housings, EV battery connector cavities (IATF 16949 compliant)
  • Medical Devices: Micro-connector molds, surgical instrument handles (ISO 13485 compliant)
  • Industrial Automation: Precision gear blanks, robotic arm components (ISO 9001 compliant)
  • Optical Components: Lens housings, laser module slots (ISO 10110 compliant)
Customization Support
We adapt every aspect of the mold to your unique hole/groove requirements:
  • CAD-Driven Customization: Accepts 3D CAD files (STEP, IGES) to replicate exact hole layouts
  • Parameter Tuning: Adjust hole diameter (0.07-5mm), groove width (0.08-10mm), and depth (0.1-20mm)
  • Material Matching: Recommend alloys based on your molding material requirements
Our Service Commitment
  • Quality Inspection: 100% testing via CMM (±0.0005mm accuracy) with detailed inspection reports
  • Traceability: Full documentation including material certificates, electroplating logs, and machining records
  • Technical Support: Dedicated engineers for design optimization and production troubleshooting
High Precision Nickel Alloy Electroplated Mold Cavity And Core With Milling Drilling Process 1
Whether you need a mold with 0.07mm micro-holes for medical connectors or 0.2mm precision grooves for automotive sensors, our high-precision nickel alloy electroplated cavities and cores deliver the accuracy, durability, and assembly compatibility your products demand.
