Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds

Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds
Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds
Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds

Large Image :  Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds

Product Details:
Place of Origin: Guangdong, China
Brand Name: HEYA
Certification: ISO9001
Model Number: HY-403
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Coated with anticorrosive oil , packed in carton box
Delivery Time: 15-20 work days
Payment Terms: T/T,D/A,D/P,Western Union
Supply Ability: 800 pcs/week
Contact Now Chat Now

Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds

Description
Product Name: Auto Lamp Mold Highlight: High-Precision Uniform Textures
Tolerance: +/-0.005mm Hardness: 43-47 HRC
Feature: Durable Processing Method: Electroforming Processing
Material: Stainless Steel, Brass, Aluminum, Tin, And Other Metal Alloys Application: Automotive, Motorcycle, Instrument, Daily Necessities, Crafts
Material: Nickel Heat Resistance: High
Corrosion Resistance: Excellent Mold Life: Long
Conductivity: High Shape: Customized
Application: Electroforming Process Durability: High
Surface Finish: Polished Tolerance: +/-0.001mm
Thickness: Depends On Design
Highlight:

lighting electroforming molds

,

custom car lamp reflector molds

,

car lamp reflector electroforming molds

Electroforming For Lighting Molds | Custom Manufacturer Of Car Lamp Reflector Molds
Product Name Auto Lamp Mold
Highlight High-Precision Uniform Textures
Tolerance +/-0.005mm
Hardness 43-47 HRC
Feature Durable
Processing Method Electroforming Processing
Material Stainless steel, brass, aluminum, tin, and other metal alloys
Application Automotive, Motorcycle, Instrument, Daily Necessities, Crafts
Specializing in high-precision optical mold solutions, we provide professional electroforming services for lighting molds and custom manufacturing of car lamp reflector molds. Leveraging the micro-level replication capability and optical-grade precision control of electroforming technology, we meet the stringent requirements of the lighting industry for light effects, structural complexity, and durability.
Electroforming for Lighting Molds: Merging Light Aesthetics with Process Precision
Catering to the decorative and functional needs of home lighting, commercial fixtures, and landscape lamps, electroforming technology endows lighting molds with unique advantages:
  • Core Process: Using high-purity electroformed nickel (purity ≥99.95%) or copper, complex textures (such as carvings, frosted patterns, and CD patterns) are precisely replicated through electrolytic deposition. The mold surface achieves a mirror finish with Ra ≤0.01μm, ensuring molded lighting components (e.g., lampshade borders, lamp base decorative rings) deliver distinct light layers and a refined texture.
Product Type Key Precision Parameters Critical Performance Indicators Suitable Injection Materials Certification Standards
Electroformed Lighting Molds Surface finish Ra ≤0.01μm;
Applicable size: φ10-300mm		 Temperature resistance: -20℃ to 150℃;
Hardness: HV ≥450;
Light transmittance uniformity of molded parts: ≥95%		 Acrylic, PC, PS ISO9001
Custom Car Lamp Reflector Molds Mirror finish Ra ≤0.008μm;
Light spot focusing deviation: ≤0.5°		 Withstands 280℃ high-temperature impact;
No deformation after 500 thermal cycles (-40℃ to 120℃);
UV aging resistance: 8,000 hours		 PC, PMMA, ASA IATF16949, ECE/SAE
Custom Car Lamp Reflector Molds: Dual Protection of Optical Performance and Durability
Focusing on core components of automotive lighting systems, we offer high-precision custom molds for car lamp reflectors, meeting strict standards for light concentration efficiency and weather resistance in headlamps, taillights, and turn signals:
  • Optical-Grade Precision: The electroformed mold surface achieves a "flawless" mirror finish (Ra ≤0.008μm), ensuring the molded reflector delivers an optical reflectivity of ≥98% with a light spot focusing deviation of ≤0.5°--compliant with international automotive lamp certifications such as ECE and SAE.
Core Advantages of Our Manufacturer
  • Technical Expertise: With 15 years of experience in electroforming molds, we are equipped with imported electroforming tanks (temperature control precision ±0.5℃) and 3D profilometers (measurement accuracy 0.1μm), ensuring every mold meets optical-grade quality standards.
  • End-to-End Service: From DFM analysis of product designs and mold flow simulation to trial optimization and mass production delivery, we provide 7×24 technical support. Small-batch trial production cycles are shortened to 10 working days.
  • Certified Quality: Our molds are certified by ISO9001. Car lamp reflector molds have been integrated into the supply chains of major automakers, while lighting molds have served renowned brands like Opple and NVC.
Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds 0
Custom Lighting Electroforming Molds Of Car Lamp Reflector Molds 1
With electroforming as our core technology, we are committed to delivering "high-precision, high-consistency, and high-durability" mold solutions for the lighting and automotive industries, ensuring every molded product combines functional value with aesthetics value.
