Customizable High Precision CD Pattern Mirror Keypad Molds for Cavities Cores

Description

Product Name:	Mold Core Pin	Tolerance:	+/-0.005mm
Application:	Die Casting Mould	Hardness:	43-47 HRC
Feature:	Durable	Processing Method:	Electroforming Processing
Highlight:	Precision Core Pins, Core Pin Die Casting	Material:	Automotive, Motorcycle, Instrument, Daily Necessities, Crafts
Material:	Nickel	Heat Resistance:	High
Corrosion Resistance:	Excellent	Mold Life:	Long
Conductivity:	High	Shape:	Customized
Application:	Electroforming Process	Durability:	High
Surface Finish:	Polished	Tolerance:	+/-0.001mm
Thickness:	Depends On Design
Highlight:	customizable CD pattern mirror keypad molds , high precision cavity core molds , CD pattern cavity mold

Customizable High-Precision CD Pattern Mirror Keypad Molds for Cavities & Cores

Product Specifications

Attribute	Value
Product Name	Mold Core Pin
Tolerance	±0.005mm
Application	Die Casting Mould
Hardness	43-47 HRC
Feature	Durable
Processing Method	Electroforming Processing
Material	Automotive, Motorcycle, Instrument, Daily Necessities, Crafts

Product Overview

With 15+ years of expertise in precision mold manufacturing, we specialize in crafting high-precision CD pattern mirror keypad molds for cavities and cores—serving industries such as consumer electronics, automotive interiors, and medical devices. Our solutions combine micron-level accuracy, intricate CD patterns, and mirror-finish surfaces, trusted by 200+ global clients including Fortune 500 companies.

Core Product Parameters

Performance Indicator	Specification	Industry Benchmark	Application Value
Dimensional Tolerance	±0.002mm	±0.005mm (standard)	Ensures precise component replication
Surface Roughness (Mirror)	Ra≤0.005μm	Ra≤0.01μm (common)	Minimizes light scattering for optical clarity
CD Pattern Line Spacing	0.05-0.5mm (±0.001mm)	±0.003mm (typical)	Guarantees uniform visual effects
Mold Life Cycle	≥1,000,000 injection cycles	500,000-800,000 cycles	Reduces long-term production costs

Key Advantages

Ultra-Precision Engineering: Using 5-axis CNC machining and advanced EDM technology, we achieve dimensional tolerances of ±0.002mm and mirror finishes with Ra≤0.005μm.

Intricate CD Pattern Replication: Our proprietary laser etching process creates CD patterns with line spacing as fine as 0.05mm, maintaining consistency across large production runs.

Material Optimization: We select from premium mold steels (H13, S136, 718H) based on application needs, offering heat resistance up to 600°C and corrosion resistance.

Complex Geometry Solutions: Capable of manufacturing molds with undercuts, thin walls (0.3mm), and conformal cooling channels, reducing cycle times by 25-30%.

Customization Options

Pattern Design: Custom CD patterns (radial, concentric, spiral), logos, or anti-glare textures
Surface Treatment: Mirror polishing, brushed finishes, PVD coatings (titanium nitride, chrome), and anodizing
Size Flexibility: From micro molds (φ10mm) to large-scale molds (500×600mm), with rapid prototyping available in 7-10 days

Applications

Smartphone camera rings, smartwatch bezels, audio device control panels, dashboard controls, LED headlight reflectors, HUD display components, endoscope lenses, diagnostic equipment housings, surgical instrument grips.

Why Choose Us

Certified Quality: ISO 9001:2015, ensuring compliance with global industry standards
Rapid Turnaround: Prototype to production in 7-12 days, with 3D simulation and virtual tryouts
Technical Support: Bilingual engineering team providing DFM analysis and mold flow simulation

Whether you need a single custom mold or high-volume production tooling, our high-precision CD pattern mirror keypad molds deliver the accuracy, durability, and aesthetic appeal your products demand.
